Ubiquiti UniFi Pro Max 24 PoE - 24-Port Layer 3 Etherlighting PoE++ Switch
Order before 3pm for same-day dispatch. Delivery in 1–3 business days.
- Official warranty
- Fast delivery
- 14-day returns
- Expert support
Warranty & returns
Every product comes with the official manufacturer warranty. Unused items can be returned within 14 days.
Product details
Multi-Gig PoE++ Switching With Etherlighting
The UniFi Pro Max 24 PoE is a 1U Layer 3 switch designed for modern networks that are moving to WiFi 7 and multi-gigabit speeds. It combines eight 2.5 GbE ports and sixteen Gigabit ports, all with PoE, so high-performance access points get the 2.5G uplink they need while cameras, phones and other devices run on the Gigabit ports.
Power delivery is serious: all eight 2.5 GbE ports and eight of the Gigabit ports support PoE++, the remaining eight provide PoE+, and the switch shares a 400W total PoE budget. Two 10G SFP+ ports connect it to your gateway or aggregation switch, and Layer 3 capabilities handle inter-VLAN routing locally.
Etherlighting lights up each port in colours you assign by VLAN, speed or device type, making it far easier to trace cables and spot problems in the rack. A 1.3" touchscreen, internal 550W power supply and full UniFi Network application management round out a switch built for professional installs.
Key Features
- 8x 2.5 GbE PoE++ ports: ideal for WiFi 7 access points
- 16x Gigabit PoE ports: 8 PoE++ and 8 PoE+
- 400W PoE budget: power a full deployment from one switch
- 2x 10G SFP+: fast fibre or DAC uplinks
- Etherlighting: colour-coded port lighting for easy cable management
- Layer 3 switching: local inter-VLAN routing
Specifications
- Model: USW-Pro-Max-24-PoE
- 2.5 GbE RJ45 ports: 8 (all PoE++)
- GbE RJ45 ports: 16 (8 PoE++, 8 PoE+)
- SFP+ ports: 2x 10G SFP+ (10G/1G)
- Total PoE availability: 400W
- Switching capacity: 112 Gbps
- Non-blocking throughput: 56 Gbps
- Forwarding rate: 83 Mpps
- MAC table size: 16,000
- Supported VLANs: 1,000
- Layer 3: yes
- Etherlighting: yes
- Display: 1.3" touchscreen
- Power supply: internal 550W AC/DC, 100–240V AC
- Max power consumption: 50W excluding PoE, 450W including PoE output
- Form factor: 1U rackmount (400–1200 mm rack depth)
- Dimensions: 442 x 325 x 44 mm
- Weight: 5.1 kg (5.2 kg with brackets)
- Enclosure: SGCC steel
- Operating temperature: -5 to 40°C
