Xiaomi Wi-Fi Range Extender AX1500

Stretch Your Wi-Fi 6 Coverage Into Every Room

The Xiaomi Wi-Fi Range Extender AX1500 wipes out dead zones by rebroadcasting your existing network with dual-band Wi-Fi 6 performance, combining up to 1201Mbps on 5GHz with 300Mbps on 2.4GHz for a fast, stable signal throughout larger homes. Dual-polarised omnidirectional antennas paired with beamforming technology lock onto your devices and push signal strength directionally, so laptops, phones, and smart TVs stay connected even in far corners of the house.

A built-in Gigabit Ethernet port lets you hardwire consoles, streaming boxes, or PCs for lag-free performance, or use Access Point mode to turn a wired connection into a fresh wireless network. It also supports EasyMesh and Xiaomi Mesh, so devices roam seamlessly between nodes without dropping the connection as you move room to room.

Setup takes minutes through the Xiaomi Home app, with a smart signal indicator to help you find the ideal placement, WPA3-SAE encryption for modern security, and flexible operating modes covering range extension, mesh networking, and access point use.

Key Features

• Wi-Fi 6 Dual-Band: Up to 1501Mbps combined throughput across 2.4GHz and 5GHz.
• Gigabit Ethernet Port: Wired connections for TVs, consoles, and PCs.
• EasyMesh & Xiaomi Mesh: Seamless roaming across a multi-node network.
• Beamforming Antennas: Directional signal boost toward connected devices.
• Three Operating Modes: Range Extender, Mesh, and Access Point.
• One-Tap Setup: Configured in minutes via the Xiaomi Home app.

Specifications

• Model: DVB4514GL
• Dimensions: 84 x 82 x 168mm
• Colour: White
• Wireless Standard: IEEE 802.11 a/b/g/n/ac/ax
• Bands: Dual-band 2.4GHz + 5GHz
• Max Speed: 1201Mbps (5GHz) + 300Mbps (2.4GHz)
• Antennas: 2 high-gain dual-polarised antennas
• Network Port: 1 x 10/100/1000Mbps LAN port
• Security: WPA-PSK / WPA2-PSK / WPA3-SAE
• Management: Xiaomi Home app (Android, iOS)
• Operating Temperature: 0 to 40°C
